MIPI Camera Modules

Bild eines MIPI Moduls
Thomas Schweitzer Tipp

Our smart tip

Profit from 30+ years of experience in embedded vision. Together we will find the right sensor and peripherals within the MIPI family for your application.
Thomas Schweitzer Tipp

Intelligent sensor solutions

Versatile in use

Icon von Gläsern

Constantly new models

Watch our MIPI camera videos!

MIPI Mania

MIPI camera modules from VC!

The right accessories for our VC MIPI® cameras

Drivers, cables, lens holders, additional boards and many more!

New MIPI camera modules

More Sony sensors for the VC MIPI® cameras

MIPI Mania

MIPI camera modules from VC!

The right accessories for our VC MIPI® cameras

Drivers, cables, lens holders, additional boards and many more!

New MIPI camera modules

More Sony sensors for the VC MIPI® cameras

Your Distribution partner for VC MIPI® camera modules

Our range of high-end VC MIPI® camera modules is being continually expanded. OEMs can choose from various global shutter and rolling shutter sensors. The VC MIPI® cameras are available with many different image sensors, e.g. from  Omnivision© and from the series Sony Pregius® und Sony Starvis®. Even non-native MIPI sensors such as Sony Pregius® IMX250 and IMX252 can be integrated.

OEMs can implement their imaging tasks with powerful CPU boards. VC MIPI® cameras are compatible with more than 20 CPU boards, including NVIDIA Jetson, DragonBoard, all Raspberry Pi boards, and all 96Boards. The high-end VC MIPI® camera modules support the MIPI CSI-2 (Camera Serial Interface) specification and meet industrial standards. In addition,  the  VC Adap96 CSI & Ethernet Adapter Board offers the perfect solution to make an intelligent VC camera from a 96board. The VC MIPI® sensor boards offer OEMs a highly versatile component for their embedded vision solutions. The compact VC MIPI® boards are just 23.5 mm wide and feature a 22-pin MIPI CSI-2 port for FPC (flexible printed circuit) cables.

The VC MIPI® cables with two or four transmission lanes can be connected to 15 and 22-pin MIPI ports. Depending on the processor, this allows communication at twice the maximum speed of USB3 cameras.

MIPI cameras are particularly suitable for applications requiring little space. The modules are ideal for multi camera applications including mobile and distributed applications like autonomous driving, UAVs, Smart City, medical technology, and laboratory automation.

All VC MIPI® cameras are made in Germany and are available in large quantities at consumer prices.

Products

VC OV9281

VC MIPI OV9281

From

59,49 €

Excl. taxes: 49,00 €

VC MIPI Module

VC MIPI IMX226

From

458,14 €

Excl. taxes: 384,99 €

VC MIPI Module

VC MIPI IMX183, Monochrome

From

630,69 €

Excl. taxes: 529,99 €

VC MIPI Module

VC MIPI IMX183, Color

From

487,89 €

Excl. taxes: 409,99 €

Bild MIPI Flyer

The compact MIPI flyer

The MIPI Flyer in cooperation with Vision Components informs you about the available VC MIPI® camera modules, MIPI accessories and compatible CPU boards.

Facts

Available VC MIPI® camera modules

VC MIPI OV9281

1/4″ CMOS sensor
Omnivision© 1.0 MPixel

1280 x 800, monochrome
120 fps / global shutter
trigger input/flash trigger output
Available

from 29,99 € (excl. VAT)*

VC MIPI OV7251

1/7.5″ CMOS sensor
Omnivision© 0.3 MPixel
640 x 480, monochrome
120 fps / global shutter
trigger input/flash trigger output
Available

from 29,99 € (excl. VAT)*

VC MIPI IMX183

1″ CMOS sensor
SONY® Exmor R® 20.2 MPixel

5496 x 3672, monochrome
24 FPS / global reset shutter
trigger input/flash trigger output
Available

from 317,99 € (excl. VAT)*

VC MIPI IMX183-C

1″ CMOS sensor
SONY® Exmor R® 20.2 MPixel

5496 x 3672, color
24 fps / global reset shutter
trigger input/flash trigger output
Available

from 281,99 € (excl. VAT)*

VC MIPI IMX226

1/1.7″ CMOS sensor
SONY® Starvis™ 12.4 MPixel

4072 x 3046, monochrome
40 fps / global reset shutter
trigger input/flash trigger output
Available

from 192,99 € (excl. VAT)*

VC MIPI IMX290

1/2.8″ CMOS sensor
SONY® Starvis™ 2.1 MPixel

1920 x 1080, monochrome
120 fps / rolling shutter

Available

from 89,99 € (excl. VAT)*

VC MIPI IMX296

1/2.9″ CMOS sensor
SONY® Pregius™ 1.6 MPixel

1440 x 1080, monochrome
60 fps / global shutter
trigger input/flash trigger output
Available

from 69,99 € (excl. VAT)*

VC MIPI IMX296-C

1/2.9″ CMOS sensor
SONY® Pregius™ 1.6 MPixel

1440 x 1080, color
60 fps / global shutter
trigger input/flash trigger output
Available

from 69,99 € (excl. VAT)*

VC MIPI IMX297

1/2.9″ CMOS sensor
SONY® Pregius™ 0.4 MPixel

728 x 544, monochrome
120 fps / global shutter
trigger input/flash trigger output
Available

from 69,99 € (excl. VAT)*

VC MIPI IMX327-C

1/2.8″ CMOS sensor
SONY® Starvis™ 2.1 MPixel

1920 x 1080, color
60 fps / global shutter

Available

from 49,99 € (excl. VAT)*

VC MIPI IMX412-C

1/2.3″ CMOS sensor
SONY® Starvis™ 12.3 MPixel

4056 x 3040, color
40 fps / rolling shutter

Available

from 99,99 € (excl. VAT)*

VC MIPI IMX415-C

1/2.8″ CMOS sensor
SONY® Starvis™ 8.3 MPixel

3840 x 2160, color
60 fps / rolling shutter

Available

from 89,99 € (excl. VAT)*

VC MIPI IMX178

1/1.8″ CMOS sensor
SONY® Starvis™ 6.3 MPixel

3072 x 2048, monochrome
60 fps / global reset shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX226-C

1/1.7″ CMOS sensor
SONY® Starvis™ 12.4 MPixel

4072 x 3046, color
44 fps / global reset shutter
trigger input/flash trigger output
Availability: October 2020

from 192,99 € (excl. VAT)*

VC MIPI IMX250

2/3″ CMOS sensor
SONY® Pregius™ 5.1 MPixel

2464 x 2056, monochrome
130 fps / global shutter
trigger input/flash trigger output
Available

from 479,99 € (excl. VAT)*

VC MIPI IMX250-C

2/3″ CMOS sensor
SONY® Pregius™ 5.1 MPixel

2464 x 2056, color
130 fps / global shutter
trigger input/flash trigger output
Availability: October 2020

from 479,99 € (excl. VAT)*

VC MIPI IMX252

1/1.8″ CMOS sensor
SONY® Pregius™ 3.2 MPixel

2064 x 1544, monochrome
160 fps / global shutter
trigger input/flash trigger output
Available

from 311,39 € (excl. VAT)*

VC MIPI IMX252-C

1/1.8″ CMOS sensor
SONY® Pregius™ 3.2 MPixel

2064 x 1544, color
160 fps / global shutter
trigger input/flash trigger output
Available

from 311,39 € (excl. VAT)*

VC MIPI IMX264

2/3″ CMOS sensor
SONY® Pregius™ 5.1 MPixel

2464 x 2056, monochrome
30 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX264-C

2/3″ CMOS sensor
SONY® Pregius™ 5.1 MPixel

2464 x 2056, color
30 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX265

1/1.8″ CMOS sensor
SONY® Pregius™ 3.2 MPixel

2064 x 1544, monochrome
50 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX265-C

1/1.8″ CMOS sensor
SONY® Pregius™ 3.2 MPixel

2064 x 1544, color
50 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX273

1/2.9″ CMOS sensor
SONY® Pregius™ 1.6 MPixel

1456 x 1088, monochrome
225 fps / global shutter
trigger input/flash trigger output
Available

from 143,99 € (excl. VAT)*

VC MIPI IMX273-C

1/2.9″ CMOS sensor,
SONY® Pregius™ 1.6 MPixel

1456 x 1088, color
225 fps / global shutter
trigger input/flash trigger output
Availability: October 2020

from 143,99 € (excl. VAT)*

VC MIPI IMX287

1/2.9″ CMOS sensor
SONY® Pregius™ 0.4 MPixel

728 x 544, monochrome
530 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX287-C

1/2.9″ CMOS sensor
SONY® Pregius™ 0.4 MPixel

728 x 544, color
530 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX290-C

1/2.8″ CMOS sensor
SONY® Starvis™2.1 MPixel

1920 x 1080, color
120 fps / rolling shutter

Availability: on request

on request

VC MIPI IMX335

1/2.8″ CMOS sensor
SONY® Starvis™ 5.0 MPixel

2592 x 1944, monochrome
60 fps / rolling shutter

Availability: Q3 2020

on request

VC MIPI IMX392

1/2.3″ CMOS sensor
SONY® Pregius™ 2.3 MPixel

1920 x 1200, monochrome
200 fps / global shutter
trigger input/flash trigger output
Availability: October 2020

from 161,99 € (excl. VAT)*

VC MIPI IMX392-C

1/2.3″ CMOS sensor
SONY® Pregius™ 2.3 MPixel

1920 x 1200, color
200 fps / global shutter
trigger input/flash trigger output
Availability: October 2020

from 161,99 € (excl. VAT)*

VC MIPI IMX415

1/2.8″ CMOS sensor
SONY® Starvis™ 8.3 MPixel

3840 x 2160, monochrome
60 fps / rolling shutter

Availability: on request

on request

VC MIPI IMX490-C

1/1.55″ CMOS Sensor
SONY® 5.4 MPixel

1920 x 1200, color
40 fps / global shutter
trigger input/flash trigger output
Availability: on request

on request

VC MIPI IMX500-C

1/2.3″ CMOS Sensor
SONY® 12.3 MPixel

4056 x 3040, color
60 fps / global shutter
AI computing & ISP on-board, Version “Chip”
Availability: on request

on request

VC MIPI IMX501-C

1/2.3″ CMOS Sensor
SONY® 12.3 MPixel

4056 x 3040, color
60 fps / rolling shutter
AI computing & ISP on-board,
Version “Package”
Availability: on request

on request

VC MIPI IMX990-SWIR

1/2″ CMOS sensor
SONY® SWIR 1.3 MPixel

1280 x 1024
134 fps / global shutter

Availability: on request

on request

VC MIPI IMX991-SWIR

1/4″ CMOS sensor
SONY® SWIR 0.3 MPixel

640 x 512
258 fps / global shutter

Availability: on request

on request

*Price for 1000+
